REDARC BMS1230S3 THE MANAGER30 Battery Management System

REDARC

$1,568.00

Why Pay $1,980.00

Quantity

All product information has been sourced from the official REDARC website. For further details, please visit www.redarcelectronics.com/au/

Battery Shunt Sensor is included with every REDARC Battery Management System.

The cutting-edge Manager30 S3 model is an all-encompassing battery management system tailored for charging auxiliary batteries in recreational vehicles and marine settings. This advanced dual battery system supports AC, DC, and solar inputs to deliver the optimal charge for auxiliary batteries.
With a focus on easy installation, the Manager30 is designed to work seamlessly with all types of vehicles and alternator systems, including those with variable voltage alternators.
Whether your setup includes Lead Acid, Gel, Calcium, AGM, or Lithium Iron Phosphate batteries, the Manager30 provides a robust DC to DC charging and maintenance solution. It ensures that all auxiliary batteries remain fully charged, offering peace of mind when battery power is necessary for maintaining home-like comforts during your travels across Australia.
The Manager30 effectively operates as six different devices: it charges an auxiliary battery while the vehicle is in motion, functions as a 240-volt charger, serves as a solar regulator, acts as a battery isolator, operates as a load disconnect controller, and includes a remote battery monitor, making it a leader in its class.

Lithium Battery Charging
Lithium batteries offer greater storage capacity relative to their size and weight, but they need specific charging conditions to perform correctly and must have an integrated cell management system. REDARC has created a charging profile within the Manager30 to complement these built-in systems.

Green Energy Priority
The Manager30 is designed to charge an auxiliary battery from multiple sources simultaneously. If 12-volt solar power is available, it prioritizes using solar power first before drawing additional charging current from mains power (if available) or DC vehicle power while driving.

MPPT Solar Regulation
The integrated Maximum Power Point Tracking (MPPT) solar regulator in the Manager30 ensures it can harness the maximum possible power from portable solar panels, even under low light conditions.

Remote Monitoring
The remote monitor displays comprehensive auxiliary battery information and charge status. Users can personalize the charging process and track the sources of charge. The intuitive graphical display ensures you are always informed and in control.

Features

Multi Stage AC-DC Battery Charger
Multi Stage DC to DC Charger
Maximum Power Point Tracking Solar Regulator
Battery Monitor
Dual Battery Isolator
Load Disconnect Controller
Super quiet operation
Charges AGM, Gel, Calcium content, VRLA, Standard Lead Acid and Lithium (LiFePO4) batteries
Tested to mains power safety standards in Australia

Specifications

Output System Voltage: 12VDC
Maximum Charging Voltage: 16.0V* (*Calcium setting in storage mode)
Output Current Rating (Cont.): 30A
Output Power: 520W
Input Fuse Rating: 50A
Output Fuse Rating: 40A
Warranty: 2 Years
Protection: Short Circuit, Surge, Reverse Polarity, Overload
Input (Operating) Voltage: 240VAC / 9 - 32VDC
Length (mm): 445
Width (mm): 185
Height (mm): 79
Weight (kg): 5.5
AC Mains Plug Type: AU, NZ, EU
Type Approval: CE
