120CM - CODE 3 PURSUIT 25 Series L.E.D. Warning Light Bar

The Next-Generation 25 Series PURSUIT L.E.D. lightbar by Code 3 was designed from the ground up, completely re-imagining what an emergency lightbar should be. The Australian Code 3 team have created the all new ProAxis Optics LED light heads with industry-leading light output, unique second level integrated LED alley, full span takedown and scene lights, plus a beautiful curved form factor that sits naturally and attractively atop the curved roofs of modern vehicles.

CONFIGURE YOUR AUSTRALIAN CODE 3 PURSUIT L.E.D. WARNING LIGHT BAR.

As a solid-state LED lightbar, the Pursuit™ uniquely incorporates two levels of lighting in a low-profile chassis. Full size upper level light heads provide uninterrupted 360º warning coverage, while dedicated lower level heads facilitate scene lighting and traffic director functions. Incorporating a patent pending diamond tooled lens array with cutting edge diffractive optics, the Pursuit light heads offer class leading performance and efficiency

With warning light output that exceeds the current market-leading lightbar, the new Pursuit LED light heads produce up to 50% more luminous intensity over a wider horizontal viewing angle range. The Pursuit lightbar design allows for a full 360º warning signal, plus 360º scene lighting.

The HazCAN network provides power and data to the Pursuit lightbar and other compatible devices while requiring only a compact four-wire harness—regardless of the number of functions.

CODE 3 PURSUIT 120cm Light Bar with REDFLEET Configurations

• TOP LEVEL *Required* - Minimum of 10 and Maximum of 18 L.E.D. Head Modules
  • WARNING MODULES
    • Choice of 10, 12, 14, 16 or 18 L.E.D. Heads
    • Colours: AMBER / BLUE / GREEN / RED

• BASE LEVEL - Maximum of 18 L.E.D. Head Modules
  • FRONT TAKE-DOWNS (TD)
    • Choice of None, 2, 4 or 6 L.E.D. Head Modules *WHITE*
  • SIDE ALLEY LIGHTS (AL)
    • Choice of None, 2, 4 or 6 L.E.D. Head Modules *WHITE*
  • R = REAR ARROW STICK - 6 L.E.D. Head Modules *AMBER*

• OPTIONAL ADD-ONS




  • VARIABLE MESSAGE DISPLAYS
    • Choice of None, Rear, Front or Both *AMBER or RED*
  • ILLUMINATED SIGN BOX (SB)
    • Choice of None, Front, Rear or Both *PRINTED DECAL INSERT*

Please note that Sign Box equipped configurations can only feature a maximum of 14 L.E.D. Head Modules for the TOP Level

Pursuit Light Bar Features

• Modular chassis construction
• 100% solid-state design
• Encapsulated control electronics
• Multi-voltage (10–30V) operation with class-leading
• EMC performance
• Serial HazCAN network control: thin, flexible wiring harness
• Integrated lens sealing system
• ECE R10, CISPR 25, RCM, SAE J845 Environmental,
• SAE J575 Vibration, IP66

Pursuit Light Bar Options

• Single colour upper light heads in red, blue or amber
• Internal illuminated sign module (protected from weathering)
• Powerful lower level forward facing full span white scene lights
• Lower level rear facing integrated traffic advisor
• Integrated solar panels for vehicle battery maintenance
• Coloured upper lens options that are independent of the lower scene lighting and traffic advisor
• Lengths: 750mm (30") to 1800mm (70") in 150mm (6") increments

Pursuit Light Bar Specifications

• 24”, 30”, 36”, 41”, 47”*, 53”, 59”*, 65”, 71”, 77”, 83” Lengths (604mm, 754mm, 904mm, 1054mm, 1204mm*, 1354mm, 1504mm*, 1654mm, 1804mm, 1954mm, 2104 mm L) W 343 mm x H 76mm
• Multi-voltage (10–30V) Operation with Class-leading EMC Performance
• Designed to meet SAE Class 1, California Title 13, ECE65 when properly configured.
• Also meets R10, IP65, CISPR 25
• 5-Year Warranty on LED Modules and Central Controller

ProAxis Optics LED light heads

• Large emitting surface optimised for warning signal
• Two-stage optical system with a patent-pending diamond tooled lens array with cutting edge diffractive optics
• Low LED junction temperature with high reliability
• Multi-voltage high efficiency LED PCA (10–30V

Integrated LED scene lights

• Powerful lower level white LED scene lights provide up to 360º of illumination
• Individually switchable (left, right, front, and back) for use as alley lights, takedown lights, work lights or scene lights
• Also provides puddle lighting close to the vehicle

Integrated traffic advisor

• The sequenced LED switching creates a smooth visual animation effect
• Eight directional patterns are available
• Amber LEDs can also be configured to flash in conjunction with the upper level warning patterns
• Lower level LEDs unaffected by upper lens colours

Internal illuminated sign

• The 300mm illuminated sign mounts inside the lightbar, protecting it from the elements
• Optimised white LED backlighting with no dark spots
• The graphics are located on the inside of the lens, protecting them from dirt and damage
• Black, blue or amber background; optional mirrored text

Unique over-moulded sealing system

• The sealing system is an over-moulded seal that is created as part of the lens during manufacture
• The over-mould seals the outer edge of the lens, plus replaces O-rings which are prone to damage
• Each membrane vent in the bridge allows the lightbar to breathe and equalise pressure

Internal features

• Silicon encapsulated control electronics
• Colour-coded grommets allow for instant identification of light module output colour
• Wiring channels and connector retaining clips keep all internals neat, organised and secure for a premium quality finished product

The Pursuit is designed to survive in the harshest of working environments—in particular the rugged conditions emergency services personnel have to work under in Australia.
The tough polycarbonate exterior lenses are fixed to a solid alloy chassis with stainless steel fittings. The LED systems are 100% solid-state, while the electronics are encapsulated for
protection against vibration.

The integrated lens sealing system in conjunction with membrane vents protect the Pursuit lightbar from moisture, dirt and dust. The membrane vents in the bridge also allow the lightbar to breathe and equalise pressure. The cable gland in the base of the lightbar seals around the ultra-thin 10mm HazCAN power and data cable
