TALON 8 Head 144 L.E.D. Full Dual Colour Directional Warning Smart Light Stick

NEW SERIES COMING SOON!!!

The TALON Series 8 head directional warning smart light stick with exclusive ARC wide-angle internal reflector optics design for superior daytime performance and visibility. Featuring full Dual Colour configuration, TALON series lights produce two full colours in every module and with it's unique low profile compact design, the TALON light stick can be installed in both internal and external applications with zero compromises on performance and visibility when activated.

The All-New TALON Series directional warning light sticks have set a new industry standard in Australia for performance, quality and full dual-colour capability.

Product Features & Technical Specifications

• 144 x Superior Daytime Performance LED's (8 Head Modules)
• Full Dual Colour Configuration
• Programmable Independent or Alternating Colour Control
• Traffic Directional Modes (Left, Right & Centre Out)
• 20+ User-Selectable Flashing Patterns
• Exclusive ARC Wide-Angle Internal Reflector Optics Design
• Brightness Rating: Suitable for Daytime Applications
• Low Profile Compact Size
• IP67 Encapsulated Internal Electronic Components
• Synchronise Multiple TALON Units
• Colourless When Not Illuminated
• ECE R65 & SAE J595 Certified
• 10-30 Multi Voltage Ready
• Suitable for Internal/External Applications
• 100,000 Operational Hours with Long Life LED Technology
• Maintenance Free Solid State Technology
• PREMIUM 6 or BASIC 12 Months Product Warranty
• Dimensions:
  • TALON Stick 1080(L) x 60(W) x 40(H)mm

Wiring Instructions

1. Black = (Negative) Ground
2. Red = (Positive) Power Supply
3. Purple = (Positive) Power On/Off (Colour 1)
4. Brown = (Positive) Power On/Off (Colour 2)
5. ***Purple + Brown combined will produce Alternating Colour Mode
6. Yellow = Pattern Change (Negative Trigger) + Group Sync
   • Pattern Change when momentarily applied to (Negative Trigger)
   • Synchronise Multiple TALON Series lights by connecting all the Yellow Wires together
7. Blue = Dimming Mode when applied to (Positive)
8. White = Steady-On when applied to (Negative)
9. Orange = Left Arrow when applied to (Positive)
10. Green = Right Arrow when applied to (Positive)
11. ***Green + Orange combined will produce Centre-Out Directional Mode
